KEY FEATURES
+Small in size, compact rugged Goggle system
+Multi-purpose: Hand-held, head-mounted or helmet mounted
+Comfortable, flip-up headgear,reliable
+Multi-coated all-glass optics,superior resolution
+Wide angle infrared illuminator,long range viewing
+Optional 3x, 5x and 8x lenses available
+Waterproof Weather and fog resistant
+Limited one-Year Warranty
|
Specification of Gen3 night vision goggles
1x lens
|
|||
| Specification | |||
| Model | MH-NVGs | ||
| Magnification | 1x | ||
| Lens system | 26.8mm, F/1.2 | ||
| FOV (Degree) | 40 | ||
| Focus range, m | 0.25 to infinity | ||
| Adjusted interpupillary distance | Yes | ||
| Eye relief distance,mm | 15 | ||
| Detection range | 220-300m | ||
| Power supply | 1CR123A type battery, 3V | ||
| Diopter setting, D | +5, -6 | ||
| Dimension, mm | 160x150x75mm | ||
| Weight | 500g | ||
| Image Intensifier Tube | |||
|
|
|
||
| Environmental Data | |||
| Operating temp. | -40℃to + 50℃ | ||
| Humidity, % | at 25℃up to 98% | ||
| Shock resistance | 5g | ||
| IP Level | IPX4 | ||
| IR-ON indicator | Yes | ||
|
Specification of Gen3 night vision goggles
3.5x lens
|
|||
| Specification | |||
| Model | MH-NVGs | ||
| Magnification | 3.5x | ||
| Lens system | 80mm, F/1.57 | ||
| FOV (Degree) | 14 | ||
| Focus range, m | 10m to infinity | ||
| Adjusted interpupillary distance | Yes | ||
| Eye relief distance,mm | 15 | ||
| Detection range | 400-500m | ||
| Power supply | 1CR123A type battery, 3V | ||
| Diopter setting, D | +5, -6 | ||
| Dimension, mm | 212*150*75mm | ||
| Weight | 700g | ||
| Image Intensifier Tube | |||
|
|
|
||
| Environmental Data | |||
| Operating temp. | -40℃to + 50℃ | ||
| Humidity, % | at 25℃up to 98% | ||
| Shock resistance | 5g | ||
| IP Level | IPX4 | ||
| IR-ON indicator | Yes | ||
