NVG–7U is based on the latest photoelectric technology research and development of new products,，The instrument adopts the high-performance generation ii/three image intensifier, with excellent performance, small volume and weight ,light, clear imaging, simple operation, high cost performance, and by replacing the objective lens (or connecting multiplier lens).
It can change magnification and so on. The product can be adjusted arbitrarily according to different eye distances. The night vision instrument has built-in digital video acquisition system, which can easily realize digital video acquisition and transmission at night and under no illumination conditions, thus realizing visual command coordination at night. Built in red detonation lamp, infrared lighting and automatic anti glare protection. The product has strong practicability and can be applied to military observation, coastal defense reconnaissance, public security surveillance, forensics, customs anti-smuggling, etc. in no illumination environment at night. It is an ideal equiEFent for the public security department, armed police force, special police force, and guard patrol.
Night Vision Goggles
Head mount with bracket
Carrying Case or hard case (optional)
Shoulder strap
Manual
Lens cleaning
|
MODEL |
NVG-7U3 |
|
IIT |
EuroGen3 |
|
Magnification |
1x |
|
Resolution ( lp/mm) |
57-64 |
|
S/N（dB） |
18-25 |
|
LuminnousSensitivity（uA/lm） |
500-900/1600 |
|
MTTF（H） |
10,000 |
|
FOV（degree） |
42+/-3 |
|
Detection sensitivity（M） |
250-300 |
|
Adjustable range of eye distance |
65+/-5 |
|
Diopter range |
+5/-5 |
|
Lenssystem |
F1.2, 25mm |
|
Coating |
Multilayer broadband coating |
|
Distance range（M） |
0.25--∞ |
|
BSP |
Yes |
|
Flip-up ,off |
Yes |
|
Flip-down, on |
Yes |
|
Material |
Aviation aluminum |
|
Power supply |
2.6-4.2V |
|
Battery type |
AA battery x 2 |
|
Infrared auxiliary light source wavelength (nm) |
850 |
|
Wavelength of red light source (nm) |
808 |
|
Digital video（optional） |
Exit Power 5V 1W |
|
Video resolution（Optional） |
Video 1Vp-p SVGA |
|
Battery life（H） |
80(IR OFF) 40(IR ON) |
|
OperatingTemperature（℃） |
-40/+50 |
|
RelativeHumidity |
5%-98% |
|
Environment rating |
IP65（IP67 optional） |
|
Weight（no battery） |
<400g |
|
Dimensions（mm) |
130x130x56 |
