MH-S8X series adopted high-performance generation II/III image intensifier, which make its observation clarity greatly improved, in 1 to 2 km distance can distinguish the size of the adult goal. In night vision mode, as long as it can satisfy the light intensity of illumination of 10-3 meter (a faint glow) conditions of use, can be field sniper operation at night.
The sight telescope volume is small, light weight, convenient operation, reliable performance, high cost performance. In addition, the aim has automatic anti-glare protection function, very suitable for urban operations. The gun aiming is equipped with independent control of infrared light, which can satisfy different working conditions of army, police operations.
Night Vision sight
Carrying Case or hard case (optional)
IR illuminator
Lens clothing
Manual
|
MODEL |
MH-S84 |
MH-S85 |
|
IIT |
EuroGen3 |
EuroGen3 |
|
Magnification |
4x |
5x |
|
Resolution ( lp/mm) |
57-64 |
57-64 |
|
Detection sensitivity（M） |
1000 |
1500 |
|
Distinguish distance（M） |
750 |
800 |
|
Lenssystem |
F1: 1.4, F85mm |
F1: 1.5, F105mm |
|
Aperture |
55mm |
65mm |
|
FOV（degree） |
11.5 |
8.5 |
|
Distance of pupil |
50mm |
50mm |
|
Graduation type |
Back Light red cursor |
Back Light red cursor |
|
Minimum mil |
1/6MOA |
1/8MOA |
|
Diopter range |
+/-5 |
+/-5 |
|
Battery type |
CR123(A)x1 |
CR123(A)x1 |
|
Battery life（H） |
40-50 |
40-50 |
|
Range of focus（M） |
8--∞ |
10--∞ |
|
OperatingTemperature （℃） |
-40 /+60 |
-40 /+60 |
|
Relative humidity |
5%-98% |
5%-98% |
|
Impact resistance |
>1000G |
>1000G |
|
Environment rating |
IP65（IP67 optional） |
IP65（IP67 optional） |
|
Dimensions（mm） |
257x92x90 |
287x92x90 |
|
Weight（no battery） |
850g |
960g |
