MHNV Hunting and Detection Laser Rangefinder LRF40 with Slope

Accurate distance measurement:
- It is capable of providing highly accurate distance readings, which is crucial for both hunting and detection. In hunting, accurate distance information helps hunters to better judge the shooting range and improve the hit rate. In detection work, such as wildlife monitoring or search and rescue, accurate distance data is essential for locating targets and making correct judgments.
Slope function:
- The slope function is a significant advantage. It takes into account the incline or decline of the terrain, allowing for more precise distance measurements in uneven terrains. This is extremely useful when hunting in hilly or mountainous areas, as it can provide a more accurate understanding of the actual distance to the target considering the elevation changes. In detection scenarios, it helps to accurately assess the distance even in complex terrains, enhancing the reliability of the data.
Compact and portable:
- Designed to be compact and lightweight, it is easy to carry and handle during outdoor activities such as hunting or field detection. Hunters can conveniently carry it in their backpacks or attach it to their equipment without adding excessive burden. This portability makes it accessible and practical for use in various outdoor environments.
Durable construction:
- Built with durable materials, it can withstand the harsh conditions of outdoor use, including impacts, vibrations, and changes in temperature and humidity. This ensures its long-term reliability and stability, allowing it to function properly even in challenging environments, which is essential for both hunting and detection tasks that often take place in the wild.
User-friendly interface:
- It usually features an intuitive and user-friendly interface, making it easy for users to operate and quickly obtain the desired information. Hunters and detection personnel can easily access and understand the measured data, enhancing the efficiency of their work and reducing the learning curve for using the device.
Fast response time:
- The device has a fast response time, enabling users to obtain distance measurements quickly. This is important in dynamic situations such as hunting, where targets may be moving, or in detection work where quick responses are needed to track and locate targets in a timely manner.
Multi-functional application:
- Apart from its primary function of distance measurement with the slope function, it may also have additional features such as azimuth measurement, which further expands its application range. It can be used not only for hunting and detection but also in other fields such as surveying and mapping, providing users with more comprehensive functionality.

Module	MHNV-LRF-40	MHNV-LRF-80
Visible Light
Resolution	1920*1080
Target Surface Dimensions	1/2.8 in
FOV	8.5°4.8°~0.35°0.28°
Optical Magnification	3.3×~80×
Laser Rangefinding
Eye safety/Level	Class1/1M
Laser wavelength	1535±5nm
Max measuring range
Large target	≥5600	≥10000
Vehicle	≥4800	≥8000
Human	≥3200	≥4500
UAV	≥1700	≥2600
Min Measuring Range	50m
Measurement Frequency	1~10Hz
Distance Measurement Accuracy	±1m
Accuracy Rate	≥98%
False Alarm Rate	≤1%
Positioning Component
Positioning mode	BeiDou/ GPS/ GLONASS multi-mode
Coordinate system	GCS/ Gauss-Kruger/ UTM/ MGRS
Intelligent Automatic Correction of Magnetic Declination
Automatic identification of local magnetic declination (at the specified location), eliminating the need for manual correction.
Electronic Compass
Azimuth accuracy	0.5° (RMS)
Pitch angle accuracy	0.1°(RMS)
Display
OLED	0.55寸
OLED Resolution	1350*1080
Working Time
Continuous working time ≥ 7 hours
External Interfaces
DC/USB/PAL/RS232
