➢White hot /black hot viewing modes
➢Display off function to save battery life
➢High resolution 640x480 OLED display
➢Brightness and contrast adjustments
➢Wifi connected your phoneandVideo output
Features:
➢640×480 resolution
➢70mm focus lens
➢50hz refresh rate
➢2x and 4x digital zoom
➢Over 3,000 meters detection range
| Main Parameter | ||||||||
| Model | MH-M670 | |||||||
| Detector type | Uncooled microbolometer | |||||||
|
Thermal sensor resolution |
640x480 px, 17μm | |||||||
| Spectral range | 8~14μm | |||||||
| Frame rate | 50Hz | |||||||
| NETD | <60mK@300k(F#1.0) | |||||||
| Micro dispaly | 0.6 inch 800×600 OLED | |||||||
| Image Processing | ||||||||
| E-Zoom | 2×/4× | |||||||
| Image adjustment | White hot/Black hot/Colour | |||||||
| Optical Parameter | ||||||||
| Focal Length | 70mm | |||||||
| Focus | Manual focus | |||||||
| F# | 1.0 | |||||||
| Foucs range | 5m～∞ | |||||||
| Field of View | 8.8°×6.6°（H×V） | |||||||
| WIFI YES | ||||||||
| Video Recording and Storage | ||||||||
| Photo Snap | Yes | |||||||
| Video Recording | Yes | |||||||
| Video storage | built-in 16Gb； | |||||||
| Video output | Analog :BNC Digital:USB2.0 | |||||||
| Observation Distance | ||||||||
|
Persons (Standing man) |
Detection：2.0k Recognition：1.0km |
|||||||
|
Vehicle (NATO Tank) |
Detection：4.0km Recognition：1.6km |
|||||||
| Power Parameter | ||||||||
| Power |
Rechargeable lithiu battery, 7.2V/2000mAH |
|||||||
|
Power consumption |
＜3.0W（@25℃） | |||||||
| Operating hours |
Continuou s working time:≥4hours |
|||||||
| Environmental parameters | ||||||||
| Seal standard | IP67 | |||||||
|
Operating Temperature |
-30°C～+60°C | |||||||
|
Storage Temperature |
-40°C～+70°C | |||||||
| Humidity | 5%～95%( Non-condensing) | |||||||
| Vibration | Sweep frequency:5-200-5Hz,G-force:10g | |||||||
| Impact | 10g/11ms Half sine wave | |||||||
| Physical parameters | ||||||||
| Product Weight | <900g（includ Battery） | |||||||
| Dimension (mm) | 240×80×80mm | |||||||
| Mount Adaptor | Standard 1/4' tripod mounting | |||||||
