PRODUCT OVERVIEW:
Thermal image MH1 series are a solid state, uncooled, long-wave infrared, magnified dedicated weapon scope intended for day and night engagements without the need to remove the sight from the rifle. And they are advanced and great helpful equipment for hunting lovers.
Thermal image can cut through total darkness, haze, dust,fog and smoke to detect target, and help to see through various animal camouflage. With proper mount with hunting gun like 1913 picatinny rail, the thermal image also helps to shoot the animals.
Features:
3 years warranty
Multiple Color Modes
6X optical lens
E-zoom 12-24X magnification
Light weight and compact design
Waterproof and shockproof
1913 Picatinny
|
Type |
Uncooled |
|
Sensor (microbolometer) |
384x288 px |
|
Material |
Ulis |
|
Image Size (output resolution) |
800x600 px |
|
Frame rate |
50 Hz |
|
Display |
Color OLED matrix, SVGA< 800x600 |
|
Thermal Sensitivity |
<50 mK |
|
Lens System |
75 mm |
|
Field of View (H x V) |
5.0x3.7 |
|
Eye Relief |
52 mm |
|
Optical Magnification |
6X |
|
Objective lens Diameter |
70mm |
|
Distance of the human detection |
1400 m |
|
Distance of the human recognition |
600 m |
|
Distance of the human identification |
350 m |
|
Reticle Color |
White & Black |
|
Brightness adjustment |
Manual |
|
Sharpness adjustment |
Automatic |
|
Start up time |
<5 sec |
|
Polarity control |
White hot / Black hot / Multiple Color Modes |
|
Environmental Rating |
Waterproof / Dust proof |
|
Battery type |
CR123 battery type |
|
Battery Life |
6 hrs |
|
Mounting bracket |
Picatinny rail |
|
Low Battery Indicator |
Yes |
|
Dimension |
300x55x50(mm) |
|
N.W. |
1.3kg |
|
Warranty |
2 years |
